Switch disconnector LBS 3200 4P 004661469

Specifications

ETI Code:
004661469
Description:
LBS 3200 4P
Class name:
Switch disconnector
Number of poles:
4
Thermal current Ith (A):
3200
Rated operational current Ie AC-21 A/B at 415V (A):
3200
Rated insulation voltage (V):
1000
Max. rated operational voltage (V AC):
415
Mounting:
Panel mounted

Documents

Product

Net weight of the product
33.8  kg
Customs tariff
85365080
logis_net_width
492  mm
logis_net_height
288  mm
logis_net_depth
226  mm

Transport packaging

Transport packaging quantity
1
EAN code for a transport packaging
3838895719021
Transport packaging weight
33.8  kg
Pallet quantity
15
Classification
EC000216
Class name
Switch disconnector
Version as main switch
Yes
Version as maintenance-/service switch
Yes
Rated permanent current Iu
3200A
Rated operation power at AC-23, 400 V
710kW
Number of poles
4
Device construction
Built-in device fixed built-in technique
Suitable for floor mounting
Yes
Degree of protection (IP), front side
IP65
ETIM Classification – Version 7.0
