Switch disconnector LBS 800 4P 004661465

Specifications

ETI Code:
004661465
Description:
LBS 800 4P
Class name:
Switch disconnector
Number of poles:
4
Thermal current Ith (A):
800
Rated operational current Ie AC-21 A/B at 415V (A):
800
Rated insulation voltage (V):
1000
Max. rated operational voltage (V AC):
415
Mounting:
Panel mounted

Documents

Product

Net weight of the product
11.753  kg
Customs tariff
85365080
logis_net_width
360  mm
logis_net_height
331  mm
logis_net_depth
166  mm

Transport packaging

Transport packaging quantity
1
EAN code for a transport packaging
3838895718987
Transport packaging weight
11.753  kg
Pallet quantity
15
Classification
EC000216
Class name
Switch disconnector
Version as main switch
Yes
Version as maintenance-/service switch
Yes
Rated permanent current Iu
800A
Rated operation power at AC-23, 400 V
450kW
Number of poles
4
Device construction
Built-in device fixed built-in technique
Suitable for floor mounting
Yes
ETIM Classification – Version 7.0
