RC surge supressor RCE10 380-400V/AC 004641703

Specifications

ETI Code:
004641703
Description:
RCE10 380-400V/AC
Class name:
RC surge supressor
Function:
Surge suppressor
For use with:
miniature and auxiliary contator CE

Documents

Product

Net weight of the product
0.014  kg
Customs tariff
85363030
logis_net_width
20  mm
logis_net_height
40  mm
logis_net_depth
10  mm

Transport packaging

Transport packaging quantity
1
EAN code for a transport packaging
7890355110560
Transport packaging weight
0.011  kg
Pallet quantity
9000
Classification
EC000683
Class name
Surge protection module
Rated voltage
380-400 AC
Function
RC-element
Rated control supply voltage AC 50 Hz
380…400V
Rated control supply voltage AC 60 Hz
380…400V
Voltage type for actuating
AC
ETIM Classification – Version 7.0
